Orbis Dualshock layout


Destructoid have dropped the bomb. They have closed the rumors with the first picture for the Orbis’s gamepad. That’s not going to be the final look, it’s a prototype. We would like to add further information about this pad:



leak destructoid



ORBIS Controller Features:

Digital Buttons:

  • Directional buttons
  • Triangle, Circle, Cross and Square
  • L1, L2 and L3
  • R1, R2 and R3
  • OPTIONS
  • SHARE (reserved for the system and cannot be accesed by the application)
  • Touchpad clicks
  • PS (reserved for the system and cannot be accesed by the application)

Analog Buttons:

  • L2 and R2

Sticks:

  • Left and Right

Touchpad:

  • Two-point multi-touch (with mechanical click)

ORBIS/PS4 Controller has an electrical capacitance touchpad where the position at wich the user’s finger is touching the pad can be detected. At most, two points can be detected at the same time.

Motion sensors:

  • 3-axes gyro sensor and 3-axes velocity sensor

Vibration feature:

  • Large motor and small motor

Light bar:

  • RGB LED (reserved for the system and cannot be accesed by the application)
